SS316L 20mA Anti Corrosion Low Cost Pressure Transmitter Standard Ceramic Pressure Sensor

Place of Origin China
Brand Name Sier
Certification CE,RoHS
Model Number SPT21C1
Minimum Order Quantity 1
Price USD15~25/Piece
Packaging Details Carton
Delivery Time 7
Payment Terms T/T, Western Union
Supply Ability 5000 pieces each month
Product Details
Housing SS304 Pressure Port SS304
Diaphragm SS316L Sealing Gasket Viton
Plug Housing Plastic Cable Φ7.5mm Polyethylene Special Cable
Load Resistance ≤(U-12)/0.02Ω(2-wire), ≥10k(3-wire)
High Light

SS316L Water Pressure Transmitter

,

20mA anti corrosion low cost pressure transmitter

,

0.5%FS diaphragm pressure transducer

Leave a Message
Product Description

Pressure Transmtter

FeaturesSS316L 20mA Anti Corrosion Low Cost Pressure Transmitter Standard Ceramic Pressure Sensor 0

1. Reliable performance, easy application
2. Short protection and reverse polarity protection
3. Low cost
4. Compact size



Introduction

SPT21C1 is economical pressure transmitter, uses standard ceramic pressure sensor and special circuit board to make it cost effective and good performance. This product is used for measure and control of liquid or gas pressure.



Specification

Pressure range 0~0.5…40MPa (0~5…400bar)
Over pressure 2 times FS
Pressure type Gauge
Process connection G1/4 male thread (or as per customer’s requirement)
Accuracy ±0.5%FS
Long term stability max. ±0.3%FS/year
Offset thermal drift ±0.02%FS/℃
Application temp. -30~80℃
Storage temp. -40~125℃
Power supply 12~28VDC
Output signal 4~20mADC(2 wires) 0/1~5VDC(3 wires)
Load resistance ≤(U-12)/0.02Ω(2-wire), ≥10k(3-wire)
Housing protection IP65
Electrical connection DIN43650 plug,M12 (or as per customer’s requirement)

SS316L 20mA Anti Corrosion Low Cost Pressure Transmitter Standard Ceramic Pressure Sensor 1



Construction and Outline Dimension

Construction material:

Housing SS
Pressure port SS
Sensor Ceramic
Sealing gasket Viton
Plug housing Plastic
Cable Polyethylene



Outline dimension:

SS316L 20mA Anti Corrosion Low Cost Pressure Transmitter Standard Ceramic Pressure Sensor 2

SS316L 20mA Anti Corrosion Low Cost Pressure Transmitter Standard Ceramic Pressure Sensor 3

Application

This product has widely been used for measurement of differential pressure of pipeline fluids in petroleum industry, chemical industry, electric power hydrology etc.
