Intelligent Anti Corrosive SS304 Industrial Pressure Transmitter Optional Signal Output
| Place of Origin | China |
|---|---|
| Brand Name | Sier |
| Certification | CE,RoHS |
| Model Number | SPT22Z |
| Minimum Order Quantity | 1 |
| Price | USD40~80/Piece |
| Packaging Details | Carton |
| Delivery Time | 7 |
| Payment Terms | T/T, Western Union |
| Supply Ability | 5000 pieces each month |
Product Details
| Housing | Aluminum-alloy | Pressure Port | SS304 Or SS316L Optional |
|---|---|---|---|
| Diaphragm | SS316L | Sealing Gasket | Viton |
| Cable Gland | Plastic | Housing Protection | IP65 |
| Over Pressure | 1.5 Times FS Or 110MPa (min. Value Is Valid) | ||
| High Light | CE SS304 pressure transmitter,IP65 anti corrosion industrial pressure transmitter,SS304 sanitary pressure transmitter |
||
Product Description
Smart Pressure Transmitter
Features
- High performance&precision
- High light liquid crystal diaplay
- Customized full test range
- Various signal output options
Specification
| Pressure range | -0.1…0～0.01…100MPa (-1…0~0.1…1000bar) |
| Over pressure | 1.5 times FS or 110MPa (min. value is valid) |
| Pressure type | Gauge/absolute/sealed gauge optional |
| Process connection | G1/2 male thread (or as per customer’s requirement) |
| Accuracy | ±0.1％FS ±0.2％FS optional |
| Indicator | 4 digit LCD |
| Display range | -1999~9999 |
| Compensated temp. | 0~50℃ |
| Environment temp. | -20~70℃ |
| Power supply | 18~36VDC |
| Output signal | 4~20mADC(2 wires)/RS485 |
| Housing protection | IP65 |
| Electrical connection | Cable gland |
Construction and Outline Dimension
Construction material:
♦Housing: Aluminum-alloy
♦Pressure port: SS304 or SS316L optional
♦Diaphragm: SS316L
♦Sealing gasket: Viton
♦Cable gland: Plastic
Outline dimension: Electrical Connection:
Order Information
Note:
1. Please pay attention that the media should be compatible with the contacted parts;
2. If any special requirements on function or specification, please contact with us freely;
